Nitto535A，NITTO 535A

NITTO 535A adopts polyester film as the base and double-sided adhesive tape with different adhesion on the front and back. It is a product specially developed for fixing resin printing plates.

Features
Apply a strong adhesive on one side and a weak adhesive on the other side.
When the resin printed board is peeled off, the tape will hardly break.

Structure
Acrylic adhesive polyester film Acrylic adhesive release layer

Characteristics

Thickness [mm] 0.12

180°Peel adhesion [N/20mm] One side 7.5, the other side 5.4

Substrate polyester film

※Laminated PET#25, 23℃, stretch Do 180° peel test under the condition of extension speed of 300mm/min.
※The above data is only an example of the measured value and is not a guaranteed value.

Usage
It is used to bond resin printing plate to the roller of the rotary machine and the printing table.
